KEMET 22μF 8V dc Aluminium Polymer Capacitor, Surface Mount 7.3 x 4.3 x 1.9mm +125°C 7.3mm [A700V226M008ATE028]; 173-4983
by KEMET
0₫
Mã kho: 1734983
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 22 µF |
| Voltage | 8 V dc |
| Mounting Type | Surface Mount |
| Technology | Polymer |
| Dimensions | 7.3 x 4.3 x 1.9mm |
| Height | 1.9mm |
| Length | 7.3mm |
| Depth | 4.3mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +125°C |
| Lifetime | 2000h |
| Series | A700 |
| Tolerance | ±20% |
| Ripple Current | 3.1A |
| Leakage Current | 7 μA |
| Polarised | Polar |
| Equivalent Series Resistance | 28mΩ |
