EPCOS 560μF 400V dc Aluminium Electrolytic Capacitor, Through Hole 35 (Dia.) x 40mm +105°C 35mm 10mm 40mm [B43544B9567M000]; 173-3472
by EPCOS
0₫
Mã kho: 1733472
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 560 µF |
| Voltage | 400 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 35 (Dia.) x 40mm |
| Length | 40mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | >175000h |
| Lead Pitch | 10mm |
| Series | B43544 |
| Tolerance | ±20% |
| Equivalent Series Resistance | 110mΩ |
| Ripple Current | 6.73A |
