EPCOS 0.22F 40V dc Aluminium Electrolytic Capacitor, Chassis Mount 76.9 x 143.2mm +105°C 76.9mm 31.7mm [B41560A7220M000]; 173-3523
by EPCOS
0₫
Mã kho: 1733523
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 0.22 F |
| Voltage | 40 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 76.9 x 143.2mm |
| Height | 143.2mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 76.9mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 3000h |
| Lead Pitch | 31.7mm |
| Series | B41560 |
| Leakage Current | 0.018 μA (Cr/μF x Vr/V)^0.85 + 4 μA |
| Ripple Current | 34A |
| Tolerance | ±20% |
| Equivalent Series Resistance | 5mΩ |
