EPCOS 10000μF 100V dc Aluminium Electrolytic Capacitor, Chassis Mount 51.6 (Dia.) x 80.7mm +85°C 51.6mm [B41458B9109M000]; 173-3493
by EPCOS
0₫
Mã kho: 1733493
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 10000 µF |
Voltage | 100 V dc |
Mounting Type | Screw Mount |
Technology | Electrolytic |
Dimensions | 51.6 (Dia.) x 80.7mm |
Height | 80.7mm |
Minimum Operating Temperature | -40°C |
Diameter | 51.6mm |
Maximum Operating Temperature | +85°C |
Lifetime | 12000h |
Series | B41458 |
Tolerance | ±20% |
Equivalent Series Resistance | 9mΩ |
Ripple Current | 10A |
