Cornell-Dubilier 6800μF 50V dc Aluminium Electrolytic Capacitor, Through Hole 30 x 35mm +85°C 30mm 10mm 35mm [SLPX682M050E5P3]; 871-2931
0₫
Mã kho: 8712931
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 6800 µF |
| Voltage | 50 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 30 x 35mm |
| Length | 35mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 30mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 1000 (Shelf) h, 3000 (Endurance) h |
| Lead Pitch | 10mm |
| Series | SLPX |
| Equivalent Series Resistance | 51 mΩ @ 20 kHz, 68 mΩ @ 120 Hz |
| Tolerance | ±20% |
| Ripple Current | 3.93 Arms @ 120 Hz, 4.91 Arms @ 20 kHz |
