Cornell-Dubilier 120μF 450V dc Aluminium Electrolytic Capacitor, Through Hole 25 x 30mm +85°C 25mm 10mm 30mm [SLPX121M450C3P3]; 871-2906
0₫
Mã kho: 8712906
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 120 µF |
| Voltage | 450 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 25 x 30mm |
| Length | 30mm |
| Minimum Operating Temperature | -25°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Lifetime | 1000 (Shelf) h, 3000 (Endurance) h |
| Series | SLPX |
| Ripple Current | 1.09 Arms @ 120 Hz, 1.60 Arms @ 20 kHz |
| Equivalent Series Resistance | 1.659 Ω @ 20 kHz, 2.212 Ω @ 120 Hz |
| Tolerance | ±20% |
