Cornell-Dubilier 35000μF 75V dc Aluminium Electrolytic Capacitor 50.8 x 117.48mm +85°C 50.8mm 22.23mm [DCMC353U075BD2B]; 872-0204
0₫
Mã kho: 8720204
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 35000 µF |
| Voltage | 75 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 50.8 x 117.48mm |
| Height | 117.48mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 50.8mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 22.23mm |
| Series | DCMC |
| Leakage Current | ≤6√CV μA, 6 mA |
| Ripple Current | 14.4A |
| Equivalent Series Resistance | 13.9mΩ |
| Tolerance | -10 → +75% |
