Cornell-Dubilier 10000μF 50V dc Aluminium Electrolytic Capacitor, Chassis Mount 34.93 x 53.98mm +85°C 34.93mm 12.7mm [DCMC103U050AA2B]; 872-0169
0₫
Mã kho: 8720169
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10000 µF |
| Voltage | 50 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 34.93 x 53.98mm |
| Height | 53.98mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 34.93mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 2000h |
| Lead Pitch | 12.7mm |
| Series | DCMC |
| Leakage Current | ≤6√CV μA, 6 mA |
| Tolerance | -10 → +75% |
| Ripple Current | 5.6A |
| Equivalent Series Resistance | 30.9mΩ |
