Cornell-Dubilier 330μF 250V dc Aluminium Electrolytic Capacitor, Through Hole 25 x 35mm +105°C 25mm 10mm 35mm [381LX331M250J032]; 871-4218
0₫
Mã kho: 8714218
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 330 µF |
| Voltage | 250 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 25 x 35mm |
| Length | 35mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Lifetime | 1000 (Shelf) h, 12000 (Ripple) h |
| Series | 381LX |
| Tolerance | ±20% |
| Equivalent Series Resistance | 308 mΩ @ 20 kHz, 603 mΩ @ 120 Hz |
| Ripple Current | 1.2 A @ 120 Hz, 1.7 A @ 20 kHz |
