Cornell-Dubilier 10000μF 35V dc Aluminium Electrolytic Capacitor, Through Hole 25 x 45mm +105°C 25mm 10mm 45mm [381LX103M035J052]; 871-3931
0₫
Mã kho: 8713931
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Capacitance | 10000 µF |
Voltage | 35 V dc |
Mounting Type | Through Hole |
Technology | Electrolytic |
Dimensions | 25 x 45mm |
Length | 45mm |
Minimum Operating Temperature | -40°C |
Diameter | 25mm |
Maximum Operating Temperature | +105°C |
Lead Pitch | 10mm |
Lifetime | 1000 (Shelf) h, 12000 (Ripple) h |
Series | 381LX |
Tolerance | ±20% |
Ripple Current | 3.2 A @ 120 Hz, 3.7 A @ 20 kHz |
Equivalent Series Resistance | 30 mΩ @ 20 kHz, 40 mΩ @ 120 Hz |
