| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Power Rating | 15 kW |
| Efficiency Class | IE3 |
| Frequency Rating | 50Hz |
| Supply Voltage | 400 V |
| Phase | 3 |
| Output Speed | 1470 RPM |
| Number of Poles | 4 |
| Mounting Type | Flange Mount |
| Shaft Diameter | 42k6 |
| Shaft Length | 110mm |
| Width | 349.5 Dia.mm |
| Depth | 561mm |
| Dimensions | 349.5 Dia. x 561 mm |
| Current Rating | 30 A |
| Maximum Output Torque | 97.45 nm |
| Bearing Type | Drive End, Non Drive End |
