The winged push barb cable tie mount in natural color requires a 0.25" (6.5 mm) panel hole diameter. It is made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness in indoor environments. It comes in packages of 100.

Name: The winged push barb cable tie mount in natural color requires a 0.25" (6.5 mm) panel hole diameter. It is made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness in indoor environments. It comes in packages of 100.
Brand: Panduit
SKU: PAP343
Price: 15500.0 VND
Availability: InStock

by Panduit

15.500₫

(Giá chưa VAT).

Mã kho: PAP343

Mã nhà sản xuất: TM2PWH25-C

Đơn vị tính: PC

Quy cách đóng gói: 100

Quantity

Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)

Wire Routing Management Protection / Cable Wire Ties Mounts Straps / Cable Tie Mounts: Panduit TM2PWH25-C

MÔ TẢ SẢN PHẨM

The winged push barb cable tie mount in natural color requires a 0.25" (6.5 mm) panel hole diameter. It is made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness in indoor environments. It comes in packages of 100.

_THÔNG SỐ KỸ THUẬT:

Application	Push Barb Cable Tie Mounts Wing Provides Added Stability. Can Be Used Where Only One Side of the Panel is Accessible.
Product Type	Cable Tie Mount
Color	Natural
Flammability Rating	UL94V-2
Environment	Indoor
Material	Nylon 6.6
Maximum Operating Temperature (°C)	85
Maximum Operating Temperature (°F)	185
Minimum Operating Temperature (°C)	-60
Minimum Operating Temperature (°F)	-76
Mount Method	Push Barb
Overall Height (mm)	18.3
Overall Length (In.)	0.71
Overall Length (mm)	18.1
Overall Width (In.)	0.61
Overall Width (mm)	15.4
Standards Met	CE Compliant, UL Recognized:E136577, RoHS Compliant
Sub Brand	NA
For Use With	Miniature, Intermediate, Standard Cross-Section Ties
