Brand:
Panduit
Panduit Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, .19" (4.8mm) x 100', flame retardant polyethylene, black. [T19FR-C20Y]; PAP143
Panduit Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, .19" (4.8mm) x 100', flame retardant polyethylene, black. [T19FR-C20Y]; PAP143
Regular price
3.875.340 VND
Regular price
Sale price
3.875.340 VND
Quantity
Hoặc gửi email trực tiếp: SKF@nguyenxuong.com
Wire Routing Management Protection / Abrasion Protection / Cable Sleeves Tools Wraps: Panduit T19FR-C20Y
MÔ TẢ SẢN PHẨM
Spiral Wrap, offers abrasion protection for wires, cables, hoses and tubing, .19" (4.8mm) x 100', flame retardant polyethylene, black.
_THÔNG SỐ KỸ THUẬT:
| Application | (1) Harness Multiple Cables Into a Single Manageable Bundle (2) Allows Breakouts of Single/Multiple Cables (3) Provides Abrasion Protection for Wire, Cables, Hoses, and Tubing |
| Note | T19FR-C20Y replaces T19FR-C20 |
| Product Type | Spiral Wrap |
| Color | Black |
| Flammability Rating | UL94V-0 |
| Includes | Installation Tool |
| Material | Flame Retardant Polyethylene |
| Resistance Properties | Flame Resistant |
| Maximum Bundle Diameter (In.) | 1 |
| Maximum Bundle Diameter (mm) | 25.4 |
| Maximum Operating Temperature (°C) | 50 |
| Maximum Operating Temperature (°F) | 122 |
| Minimum Bundle Diameter (In.) | 0.125 |
| Minimum Bundle Diameter (mm) | 3.2 |
| Minimum Operating Temperature (°C) | -40 |
| Minimum Operating Temperature (°F) | -40 |
| Outer Diameter (In.) | 0.19 |
| Outer Diameter (mm) | 4.8 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Standards Met | UL Recognized E141152 |
| Wall Thickness (In.) | 0.03 |
| Wall Thickness (mm) | 0.8 |
| Part Features | Allows breakouts of single/multiple cables, Provides abrasion protection for wire, cables, hoses and tubing. Multiple colors allow for easy identification of cable bundles. Installation tool is supplied and the spiral wrap is reusable. |
