| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Supply Voltage | 12 → 240 V ac/dc |
| Time Range | 0.1 s → 10 min |
| Mode of Operation | Star Delta Delay |
| Mounting Type | Plug In |
| Number of Timer Functions | 1 |
| Time Increment | Minutes, Seconds |
| Power Supply | External |
| Contact Configuration | 2 x SPDT |
| Current Maximum | 0.333333333333333 |
| Terminal Type | 11-Pin Connector |
| Minimum Voltage | 12 V ac/dc |
| Width | 24mm |
| Minimum Operating Temperature | -20°C |
| Depth | 74mm |
| Time Delay | 100 ms |
| Length | 48mm |
| Maximum Operating Temperature | +65°C |
| Switch Configuration | 2 x SPDT |
