XP Power SIP100 DC-High Voltage DC Non-Isolated Converters 1 0 → 10mA 25 → 100V dc 1W [SIP100]; 136-0440
by XP Power
0₫
Mã kho: 1360440
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 25 → 100V dc |
| Input Voltage Range | 4 → 6.7 V dc |
| Power Rating | 1W |
| Output Current | 0 → 10mA |
| Number of Outputs | 1 |
| Minimum Temperature | -20°C |
| Maximum Temperature | +70°C |
| Load Regulation | 0.001 |
| Line Regulation | 0.002 |
| Ripple And Noise | <10mV Pk-Pk |
| Weight | 7.1g |
| Depth | 19.05mm |
| Width | 4.06mm |
| Maximum Input Current | <350 (Full Load) mA, <75 (No Load) mA |
| Length | 36.8mm |
| MTBF | 2.03Mh |
| Power Signal Conversion Type | DC-DC |
| Series | SIP Series |
