XP Power CB101N DC-High Voltage DC Non-Isolated Converters 1 100μA -10kV 1W [CB101N]; 123-8389
by XP Power
0₫
Mã kho: 1238389
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | -10kV |
| Input Voltage Range | 11.5 → 16 V dc |
| Power Rating | 1W |
| Output Current | 100µA |
| Number of Outputs | 1 |
| Minimum Temperature | -10°C |
| Maximum Temperature | +60°C |
| Maximum Input Current | <100 (No Load) mA, <225 (Full Load) mA |
| Protection Features | Over Voltage Protection |
| Weight | 85g |
| Ripple And Noise | <0.1% Pk-Pk |
| MTBF | >2600000h |
| Power Signal Conversion Type | DC-DC |
| Series | CB |
