STMicroelectronics 300V 100A, Dual Diode, 4-Pin ISOTOP STTH20003TV1 [STTH20003TV1]; 168-6628
0₫
Mã kho: 1686628
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Mounting Type | Panel Mount |
| Package Type | ISOTOP |
| Maximum Continuous Forward Current | 100A |
| Peak Reverse Repetitive Voltage | 300V |
| Diode Configuration | Isolated |
| Rectifier Type | Switching |
| Diode Type | Silicon Junction |
| Pin Count | 4 |
| Maximum Forward Voltage Drop | 1.2V |
| Number of Elements per Chip | 2 |
| Diode Technology | Silicon Junction |
| Peak Reverse Recovery Time | 90ns |
| Peak Non-Repetitive Forward Surge Current | 100A |
