Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 12 → 36V dc |
| Output Voltage | 9V dc |
| Number of Outputs | 1 |
| Output Current | 500mA |
| Mounting Type | PCB Mount |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Efficiency | 93/90% |
| MTBF | 2000 (Minimum)kh |
| Load Regulation | ±0.3 (Typ.)% |
| Line Regulation | ±0.4% |
| Ripple And Noise | 75mV Pk-Pk |
| Power Signal Conversion Type | DC-DC |
| Maximum Input Current | 1.5mA |
| Switching Frequency Range | 550 → 850kHz |
| Length | 11.6mm |
| Depth | 10.16mm |
| Allowed Circuit Configurations | Parallel |
| Weight | 1.8 (Typ.)g |
| Width | 7.55mm |
