Brand:
Panduit
Panduit Corrugated loom tubing solid wall, .31" (7.9mm) x 100', polyethylene, orange. [CLTS35F-C3]; PAK536
Panduit Corrugated loom tubing solid wall, .31" (7.9mm) x 100', polyethylene, orange. [CLTS35F-C3]; PAK536
Regular price
0 VND
Regular price
Sale price
0 VND
Quantity
Hoặc gửi email trực tiếp: SKF@nguyenxuong.com
Wire Routing Management Protection / Abrasion Protection / Corrugated Loom Tubing Fittings: Panduit CLTS35F-C3
MÔ TẢ SẢN PHẨM
Corrugated loom tubing solid wall, .31" (7.9mm) x 100', polyethylene, orange.
_THÔNG SỐ KỸ THUẬT:
| Application | Provides Protection for Cables, Crush Impact and Abrasion Resistant, Hold in Place with Push Type Cable Ties Adhesive or Push Type Mounts. |
| Product Type | Corrugated Loom Tubing |
| Color | Orange |
| Environment | Indoor |
| Flammability Rating | UL94-HB |
| Inside Diameter (In.) | 0.35 |
| Inside Diameter (mm) | 8.9 |
| Material | Polyethylene |
| Resistance Properties | Crush Impact and Abrasion Resistant |
| Maximum Operating Temperature (°C) | 50 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°F) | 122 |
| Minimum Operating Temperature (°F) | -40 |
| Nominal Diameter (mm) | 7.94 |
| Outer Diameter (In.) | 0.5 |
| Outer Diameter (mm) | 12.7 |
| Overall Length (ft.) | 100 |
| Overall Length (m) | 30.5 |
| Standards Met | RoHS Compliant |
| Part Features | Provides protection for cables, Crush impact and abrasion resistant, Hold in place with push type cable ties adhesive or push type mounts |
